Product Description

Compression Testing Machine Hand Operated
Item code: ECTM-3

For Compression test on Concrete or similar materials. Suitable for use on Concrete Cubes of any size upto 5cm x 5cm x 5cm, 7.06 x 7.06cm, 10cm x 10cm x 10cm, and 15cm x 15cm x 15cm also on 10 x 20cm and 15 x 30cm high Concrete Cylinders. The load is applied thru hydraulick assembly.The lower platen is on the Hydraulic ram, and upper having a spherical seating is adjustable. The machine is provided with an air release valve and the load is automatically indicated on the 15 cms diam hydraulic pressure calibrated against an N.C.B.M. tested Proving Ring and fitted with a legless max pointer in addition to the ‘live’ pointer.

Compression Testing Machine, Hand Operated, 25,000 kgf (250 KN, channel) Model : double plunger pump with hydraulic pressure gauge. Our own Calibration
