Digital Solar Charge Controller by Ofca Power Technology Private Limited

We are involved in present an exclusive range of Digital Solar Charge Controller. Our products are available in diverse specifications that meet on exact requirements of our patrons.

Description:

This is a solar charge controller 20A ~30A that have automatic max. power point tracking function with high efficiency that almost 30%~60% higher than traditional charge controller. It also features the functions of system voltage auto recognition, wide rang of PV input ,charge for all kinds of battery,automatic discharge control,RS 232 / LAN communication function and so on. It is very high-end product for solar market.

Feature:

• MPPT charge mode,conversion efficiency up to 99%
• 12V/24V/48V system auto recognize;
• Wide range of PV input with max. is DC150V.
• Memory function,Save setting function: date,time,generating capacity record and so on .
• Charge mode: 3 stages (fast charge,constant charge ,floating charge) .It prolongs service life of the batteries .
• Discharge mode: ON/OFF mode, double time control mode,PV voltage control mode ,PV voltage+time delay mode and so on
• Selected battery types: sealed lead acid, vented, gel, NiCd battery. Other types of the batteries can also be defined.
• Most information could be provide by LCD and LED like: model no.,PV input voltage,battery type,battery voltage,charging current,charging power,working status and so on. Also customer's information like company name,website and logo can be added into Solar Eagle software.
• RS232 and LAN communication port. IP and Gate address could be user define it satisfy global area.And communication protocol can be provided to manage all information.
• The upper computer software is displayed in 11 languages, it could show work status and be set parameters of the discharge system.
• With intelligent design,the device can be upgraded online lifelong.
• Compliance with the 2002/95/EC environment protecting demand,doesn't include the Cadmium, hydride and fluoride etc material
• Equipment integrity: controller + CD-ROM(microcomputer software) + communication wire + temperature sensing wire + Anderson terminals;
• CE,ROHS certifications approved.
