GC Nitrogen Air Combination Generator By PCI Analytics Private...

Featured Suppliers

How it works

Submit an enquiry to a product.
Wait for a call from nearest supplier from your area.
Get quote and product details.
Choose best from them.

Recently Added Suppliers

Product Description

Features

• Nitrogen & Air Generator produces a continuous flow of high purity Nitrogen at selected pressure.
• The modular pressure swing adsorption (PSA) unit operates with alternating pressure increase and decrease.
• Untreated air flows under pressure through the reaction towers containing molecular sieve adsorber.
• Moisture, CO, CO2, THC, Oxygen and other unwanted components in the air are adsorbed, leaving Zero Air & Nitrogen Gas of required purity.
• Nitrogen & Air combination generator is compact (2in 1) & also cost effective and the compressor for generating both the gases is common.
• Special Combination of Nitrogen, Zero Air for GC & Zero Air for TOC model is also available.
• Microcontroller digital display

Technical Specification:

Principle Specifications	N2 Specifications OF NAG-01/NAG-01A	AIR Specifications OF NAG-01/NAG-01A
Moisture	< 2 ppm	< 2 ppm
Oxygen	< 5 ppm	—
Total Hydro Carbon (THC)	< 0.3 ppm	< 0.3 ppm
CO & CO2	< 2 ppm	< 2 ppm
Purity	UHP / GC grade	UHP / GC grade
Micron particulates	< 0.01µ	< 0.01µ
Capacity of NAG-01	500ml/min at 5 kg/cm²	4000ml/min at 5 kg/cm²
Capacity of NAG-01A	200ml/min at 5 kg/cm²	1500ml/min at 5 kg/cm²
Capacity of NG-02/02M	500ml/min to 10 LPM at 5kg/cm²	—
Method of Purification	Pressure Swing Adsorption (PSA) & Depressurisation	Pressure Swing Adsorption (PSA) & Depressurisation
Room Temperature	5 ºC - 25 °C	5 ºC - 25 °C
Start up time	2 hr / programmable by timer	10 min
Electrical requirements for NAG-01 & NAG-01A	230 V AC, 50 Hz, 1 ph, 5 Amp	230 V AC, 50 Hz, 1 ph, 5 Amp
Size of Generator without compressor (in mm) (approx.)	600 H x 400 W x 700 D for NAG-01	—
Size of Generator without compressor (in mm) (approx.)	600H x 400 W x 700 D for NAG-01A	—
Net weight of generator (in kg) (w/o compressor) (approx.)	kg of NAG-01	—
Net weight of generator (in kg) (with compressor) (approx.)	NAG-01A	—

Salient Features:

• Deliver constant pressure & flow
• Fully Automatic Programmable System
• Easy Maintenance and space saving
• Effortless and easy operation
• Improves instrument performance
• Fully regenerative, durability with PSA technology

Applications:
• GC-FID, FPD, NPD, TCD, AED
• GC-MS, LC-MS-MS, ICP / NMR
• FTIR / IR, ELSD detector
• Purging, Ampule Filling
• Thermal instruments, Turbo Evaporator (N2 Concentrator)
• All Analytical Instruments
